BOM Hardware / Fastener Kit - Prusawire - R1
Learn more at the Printables page
Get 110% of every nut, bolt, and screw required to build the R1 version of the Prusawire!
Includes
| Item Name | Reference Number | Quantity |
|---|
| M2x10mm Self-Tapping Screw for Plastic - Hex Drive |
M2x10STS |
8 |
| Metric Hex Nut - Zinc Coated Steel - M3x0.5 - Grade 8 - DIN934 |
NR3CLZ |
50 |
| Metric Nylon Locking Hex Nut - Black Stainless - M3x0.5 - DIN985 |
NN3BLKSS |
12 |
| T-Nut - Drop In/Roll In - 20 Series - 6mm Slot Width - M3 Threads |
2020M3RI |
13 |
| Metric Thin Square Nut - Zinc Plated - M3x0.5 - Class 4 - DIN562 |
KB3-HW-SQU-NUT-M3-THIN |
21 |
| Metric Button Head Screw - Black Oxide - M3x8x0.5 - Grade 10.9 - ISO7380 |
SB3X8 |
5 |
| Metric Button Head Screw - Black Oxide - M3x10x0.5 - Grade 10.9 - ISO7380 |
SB3X10 |
6 |
| Metric Button Head Screw - Black Oxide - M3x16x0.5 - Grade 10.9 - ISO7380 |
SB3X16 |
3 |
| Metric Button Head Screw - Black Oxide - M3x30x0.5 - Grade 10.9 - ISO7380 |
SB3X30 |
3 |
| Metric Flat Head Screw - Black Oxide - M3x12x0.5 - Grade 10.9 - DIN7991 |
SF3X12 |
17 |
| Metric Socket Head Cap Screw - Black Oxide - M3x8x0.5 - Grade 12.9 - DIN912 |
BSH3X8 |
17 |
| Metric Socket Head Cap Screw - Black Oxide - M3x10x0.5 - Grade 12.9 - DIN912 |
BSH3X10 |
7 |
| Metric Socket Head Cap Screw - Black Oxide - M3x12x0.5 - Grade 12.9 - DIN912 |
BSH3X12 |
22 |
| Metric Socket Head Cap Screw - Black Oxide - M3x14x0.5 - Grade 12.9 - DIN912 |
BSH3X14 |
6 |
| Metric Socket Head Cap Screw - Black Oxide - M3x16x0.5 - Grade 12.9 - DIN912 |
BSH3X16 |
7 |
| Metric Socket Head Cap Screw - Black Oxide - M3x20x0.5 - Grade 12.9 - DIN912 |
BSH3X20 |
18 |
| Metric Socket Head Cap Screw - Black Oxide - M3x25x0.5 - Grade 12.9 - DIN912 |
BSH3X25 |
6 |
| Metric Socket Head Cap Screw - Black Oxide - M3x30x0.5 - Grade 12.9 - DIN912 |
BSH3X30 |
27 |
| Metric Socket Head Cap Screw - Black Oxide - M3x35x0.5 - Grade 12.9 - DIN912 |
BSH3X35 |
4 |
| Metric Socket Head Cap Screw - Black Oxide - M3x40x0.5 - Grade 12.9 - DIN912 |
BSH3X40 |
8 |
| Metric Button Head Screw - Black Oxide - M4x10x0.5 - Grade 10.9 - ISO7380 |
SB4X10 |
4 |
| Metric Hex Nut - Zinc Coated Steel - M5x0.8 - Grade 8 - DIN934 |
NR5CLZ |
4 |
| T-Nut - Drop In/Roll In - 20 Series - 6mm Slot Width - M5 Threads |
2020M5RI |
10 |
| Metric Button Head Screw - Black Oxide - M5x8x0.8 - Grade 10.9 - ISO7380 |
SB5X8 |
8 |
| Metric Button Head Screw - Black Oxide - M5x30x0.8 - Grade 10.9 - ISO7380 |
SB5X30 |
4 |
| 3x6x0.5mm Shim Ring / Washer - Pack of 50 - DIN988 |
SS-3605-50 |
1 |
| Brass Heat Set Threaded Insert for Plastic - M3x5x4mm |
HSI354 |
75 |
KB3-KIT-HW-PW-R1(PAL)
5 Items
