LDO Nitehawk-36 (NH36) USB Tool Head Kit - Rev C+
$42.99
Nitehawk is a USB tool head PCB with a RP2040 MCU, TMC2209, Accelerometer all integrated into one board. The form factor is based on the popular 36mm Nema 14 mounting standard.
Now Shipping Revised (Rev C+) - includes fully over-molded umbilical cable
LDO Nitehawk-36 (NH36) USB Tool Head Kit
Now Shipping Revised (Rev C+)
Learn more at LDO Documentation
See the GitHub page
Nitehawk-36 is a toolboard featuring RP2040 MCU, TMC2209 stepper drive, ADXL345 accelerometer, and USB port. Nitehawk-36's USB based connection method allows for a simple and easy setup compared to other CAN toolboards. The USB connnection also allows for a secondary USB port to connect your nozzle webcam or eddy current probe.
Nitehawk-36 Features
- Convenient wiring, no more complicated and error prone breakout cables
- USB Klipper connection, no additional software or hardware setup compared to CAN
- Secondary USB port, an onboard USB port allows you to connect a second USB device to your toolhead without an additional umbilical cable
- Custom toolhead cable, a single combined USB data and power cable rated for drag chain use, but can also be used in umbilical configuration
- Convenient Input Shaping, run input shaper calibration at anytime with an onboard accelerometer
- Tacho enabled HEF, the hotend fan port is three pin tachometer compatible, allowing for additional diagnostics and safety
Package Includes
What Included In Kit
Quantity
Toolhead PCB
1
USB Adapter PCB
1
USB Umbilical Cable 2.15m
1
USB-A to USB-C Data Cable, 0.4m
1
24V Power Cable
1
USB Hookup Cable
1
Self-Tapping Screw, M2x10
3
Machine Screw, SHCS, M3x8
2
Machine Screw, SHCS, M3x12
4
MicroFit3 style Male Connector, 3x2pin
1
MicroFit3 style Female Crimp Terminal
8
XH2.5 Female Connector, 4pin
1
XH2.5 Female Crimp Terminal
8
PH2.0 Female Connector, 2pin
5
PH2.0 Female Connector, 3pin
3
PH2.0 Female Crimp Terminal
30
Ferrule, 1008
4
Ferrule, 0508
4
Frequently Asked Questions
- What extruders are compatible with the Nitehawk-36?
- The LDO Nitehawk-36 (NH36) is compatible with the Orbiter 2, Galileo 2 Standalone (G2SA), WristWatch G2 (WWG2), LGX Lite, LGX Lite V2, Sherpa Micro, and any other extruders designed for a 36mm pancake stepper motor.
- What is the difference between Nitehawk-36 and Nitehawk-SB?
- Nitehawk-36 is a universal design for round pancake motors that works with various toolheads. In contrast, the Nitehawk-SB is designed for the Voron Stealthburner toolhead with a Clockwork 2 or Galileo 2 extruder.
- Can I connect additional USB devices to the Nitehawk-36?
- Yes, the Nitehawk-36 features a built-in USB hub allowing you to connect a nozzle webcam, Beacon surface scanner, Cartographer probe, Eddy current probes and more.
- What improvements were made in REV C+?
- The Rev C+ (v1.4) addresses problems from earlier versions, including better reliability and component quality, enhanced USB hub functionality, improved thermal management, fully overmolded umbilical cable for durability, and metal backing to protect against EMI.
LDO-NH-36-C
